Philips M3014A Bidirectional MSL Interface with Flexible Cable M3012-66421 for IntelliVue

Philips M3014A Bidirectional MSL Interface

Philips M3014A Bidirectional MSL Interface with Flexible Cable M3012-66421 for IntelliVue

► Brief Description

This component is part of the housing connection assembly for the M3014A series expansion module. It is a general-purpose MSL bidirectional signal interface flexible cable assembly (connection assembly) for the M3014A CO2 expansion module. M3012-66421 specifically refers to a connection structure containing a flexible cable used to connect the module's front-end interface board and main circuit board.

Function:

 1. It acts as a communication "bridge" between the M3014A module and the monitoring host.

 2. When the M3014A is inserted into the monitoring host, this flexible cable is responsible for establishing the MSL data connection.

Application:

When the M3014A module housing is damaged, the insertion/removal mechanism malfunctions, or internal wiring is broken, technicians can use this assembly containing the flexible cable to repair the module.

► Specification

► Bidirectional MSL Interface

MSL (Measurement Signal Link): The internal communication bus of the Philips IntelliVue monitoring system, used to transmit data and power between the monitor and the measurement module (MMS/server).

Bidirectional: This interface can receive measurement data from the module (upload) and control signals and power from the host (download).

Flexible Cable: A flat ribbon cable connecting the module's front-end interface and the internal circuit board. It provides physical buffering during module insertion and removal and transmits the MSL signal.
