Philips IntelliVue Portable Bedside MX450 Patient Monitor

Announcer: PMR Med Release Time:2026-07-11

Philips  MX450 Monitor

 Philips IntelliVue Portable Bedside MX450 Patient Monitor



► Product Introduction


1. Covers the full range of vital signs. The MX450 tracks ECG, SpO₂, NIBP, respiration, and temperature as standard. Add‑on modules bring in invasive pressures, CO₂, and cardiac output—so the monitor scales from low‑acuity wards to critical care.

2. Travels with the patient. Its detachable X2 module stays connected to the same sensors when the patient moves, eliminating cable swaps and monitoring gaps. The integrated handle and lightweight build make bedside‑to‑bedside transfers effortless.

3. Saves time with smart insights. Built‑in tools like early warning scores, ST‑segment mapping, and sepsis screening flags turn raw data into actionable alerts.

4.Connects without extra boxes. It talks directly to EMR systems and the central station via wired or wireless networks no separate device concentrator required.


► Specification


Dimensions (W x H x D)

327 x 288 x 182 mm

Weight

< 6 kg

Display Type

12" WXGA active matrix colour TFT LCD

Display Resolution

1280 x 800 (WXGA 16:10)

Useful Screen Area

261.1 x 163.2 mm

Pixel Size

0.204 x 0.204 mm

Wave Speeds

6.25, 12.5, 25, 50 mm/s

Line Voltage

100–240 V

Current

1.2–0.5 A

Frequency

50/60 Hz


► Detailed Photos
