Philips AV FM20 FM30 Fetal Monitor Display Assy 5 Wire Part 453564150521

Philips FM20 FM30 Display

Philips AV FM20 FM30 Fetal Monitor Display Assy 5 Wire Part 453564150521

► Product Introduction

This assembly is the primary user interface for the FM20 and FM30, displaying fetal and maternal data while enabling touch interaction. It comes as a complete service replacement unit that includes the display and all necessary internal components.

The assembly integrates a 6.5-inch TFT (Thin-Film Transistor) color LCD panel with a five-wire resistive touchscreen and an LED backlight. All these components are connected to a Display Adapter Board (M2703-66440) and fitted into a display housing. This adapter board connects to the monitor's main system via a 50-pin ribbon cable.

► Specification

► Detailed Photos

Tags： Philips FM20 FM30 Fetal Monitor, Display Assy, Fetal Monitor Display,
