Philips Heartstart XL+ Defibrillator ECG Interface Panel Board Assembly 453564126041

Philips Heartstart XL+   ECG Panel Board

Philips Heartstart XL+ Defibrillator ECG Interface Panel Board Assembly 453564126041

► Product Overview

 This Interface Panel Board (part number: 453564126041), specifically designed for the HeartStart XL+ defibrillator/monitor. This interface panel is a key interface on the left side of the device chassis, providing the physical interface for raw cardiac electrical signals to enter the monitoring system. The assembly includes a color-coded, foolproof multi-pin connector for connecting the patient's ECG cable, and precision conductive traces that directly transmit the input analog signal to the main processor board.

Upon receiving the signal, the main processor board transmits the ECG signal to the PCA processor, where the signal is amplified, filtered, and digitized for algorithmic processing. The assembly features a robust, shock-resistant medical-grade housing capable of withstanding the mechanical stress of repeated cable insertion and removal.
