453564403401 453564403391 USB Interface Board MSH Board for Philips TC10 ECG Machine Patient Monitor

Philips TC10 ECG Machine Patient Monitor

453564403401 453564403391 USB Interface Board MSH Board for Philips TC10 ECG Machine Patient Monitor

► Product Overview

This is an original USB Interface Board (MSH Board) specifically designed for the Philips TC10 ECG Machine. As seen in the images, the circuit board features a green PCB substrate with densely populated electronic components. Key features include the gold finger connector on the lower left (for insertion into the main unit), an RJ45 network port on the upper right, and a USB Type-B port on the lower right. This board serves as the core communication module for the TC10 ECG Machine, responsible for transmitting collected ECG signals to computers or the hospital's Medical Information System via USB or network ports, ensuring accurate data export and archiving for diagnostic purposes.

This USB Interface Board serves as the "communication hub" for the Philips TC10 ECG Machine. Its primary function is to establish a bridge between the ECG machine and the outside world. Specifically, it handles all incoming and outgoing data streams, including exporting ECG waveform data to a USB drive for doctors to analyze on a computer, or uploading data directly to the hospital's Electronic Medical Record system via an Ethernet cable. Without this board, the TC10 would only function as a standalone device, unable to achieve digital data management and remote transmission, which would significantly limit its application value in a modern digital medical environment.

► Specification

► Detailed Photos

Tags： Philips TC10 ECG Machine, USB Interface Board, 453564403391 453564403401 MSH Board,
